Two-Head Door and Window Making Machine for Cutting Aluminum_Aluminum window machine

Two-Head Door and Window Making Machine for Cutting Aluminum

Time：2025-01-11　Browse：11次

Product Description

Voltage	380 V; 50 HZ
Power	2*3kw
Air pressure	0.5-0.8 MPa
Main motor rotation speed	2800r/min
Cutting length	495*4200mm
Saw blade specification	φ550 x φ30
Angle cutting tolerance	±5°
Cutting profile surface roughness	Ra12.5um
Cutting angle	90° and 45°inward
Repeat Locating length	≤0.3mm
Planeness of cutting surface	≤0.10mm
Dimension	550012001700mm
Weight	1220kg

Performance features:

1.1 This machine is used for processing the aluminum and PVC profiles at angle of 45°,90°
1.2 The swaying stable feeder is adopted.
1.3 The pneumatic driving system is used in profiles clamping and cutting.
1.4 Carbide saw blade gives accurate processing and high endurance.
1.5 The two heads can work independently or together.
1.6 Cutting off required length and two end angles are available by one processing.
1.7 It has the features of easy operation and high accuracy.

Company Profile

Jinan YBKE Machinery Co.,Ltd specializes in the production of insulating glass machine, UPVC and aluminum window & door machine for over 13 years experience. Each machine has been strictly tested before delivery. We can offer customized solutions help customers meet real demands. We hope to build long-term friendly business relationship with our partners, and realize win-win cooperation. Welcome to visit our factory on-site or online!!!

Packing & Delivery

1.For full container load, usually wrapped in stretch films or simultaneously fixed with iron frame. 2.For open top container load, put on top grade plastic overcoat and tarpaulin to protect the equipment from moisture and water. 3.For less than container load, packed in standard export plywood case. 4.Delivery time: Small and few machines: in 5-10 days after receiving pre-payment. 5.Big or many machines: more than 25 days after receiving pre-payment.
